• Economical choice for Air-Conditioning and Refrigeration field
• Different types of insulation available
• Reduction of installation time
• Fast delivery
Features：
• Economical choice for Air-Conditioning and Refrigeration field.
• Fast delivery
• Reduction of installation time
• Different types of insulation available.
| Dimentions | |||||
| Part Number | Copper Tube O.D (inch) | Insulation Thickness (mm) | Copper Tube O.D X Wall Thickness (mm) | Aluminum Tube O.D X Wall Thickness(mm) | Length(m) |
| XLALC1438 | 1/4 - 3/8 | 8 x 8 | 6.35 x 0.7 – 9.52 x 0.7 | 6.35 x 1.0 – 9.52 x 1.0 | 3,4,5...20 |
| XLALC1412 | 1/4 - 1/2 | 8 x 8 | 6.35 x 0.7 – 12.70 x 0.7 | 6.35 x 1.0 – 12.70 x 1.2 | 3,4,5...20 |
| XLALC1458 | 1/4 - 5/8 | 8 x 8 | 6.35 x 0.7 – 15.88 x 0.8 | 6.35 x 1.0 – 15.88 x 1.2 | 3,4,5...20 |
| XLALC3858 | 3/8 - 5/8 | 8 x 8 | 9.52 x 0.7 – 15.88 x 0.8 | 9.52 x 1.0 – 15.88 x 1.2 | 3,4,5...20 |
| XLALC3834 | 3/8 - 3/4 | 8 x 8 | 9.52 x 0.7 – 19.05 x 0.8 | 9.52 x1.0 – 19.05 x 1.2 | 3,4,5...20 |
| XLALC1234 | 1/2 - 3/4 | 8 x 8 | 12.70 x 0.7 – 19.05 x 0.8 | 12.70 x 1.2 – 19.05 x 1.2 | 3,4,5...20 |
